The Web-Based Smart Switch TEG-S240WS is the ideal switch for Network segmentation. It has 24 ports 10/100 / 1000Mbps Auto-Sensors and
Auto-MDIX for easy installation. The TEG-S240WS supports web browser configuration; the network administrator can use the web browser to configure
the speed of the port, port-base VLAN and QoS, and also monitor the status of each port which provides a simple, measurable and flexible migration
to manage new applications or types of data. TRENDnet's TEG-S240WS is powerful and easy-to-use while reducing broadcast traffic and
enhancing network security.
- 24 Gigabit ports 10/100 / 1000Mbps Auto-negotiation and Auto-MDIX
- Transfer mode in Full / Half-Duplex on each port (1000Mbps in Full-Duplex only)
- Reception and transmission in "Full Wire-Speed Non-Blocking" mode
- Switching method "Store and Forward"
- 400K bytes RAM data buffer and MAC table addresses 8K entries
- On the front panel LED LED lights
- Standard IEEE 802.3x flow control for full-duplex mode; Back Pressure flow control for half-duplex mode
- Proprietary Windows Based Management / Monitoring Utility (Similar to SNMP Trap)
- Port-Based VLAN and Port-Based IEEE 802.1p QoS (High / Normal)
- Supports Trunking and Port Mirroring
- "Port Setting" function, users can program the availability, speed, duplex mode and flow control of each port
- Easy Confirguration via Web Browser
- 19 "Rackmount Standard Design
- Equipment
- LAN standards:
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T, 100Base-FX
- Network Media:
- Ethernet: UTP / STP Cat. 3, 4, 5
- Fast Ethernet: UTP / STP Cat. 5
- Gigabit: UTP / STP Cat. 5 / 5E
- Protocol:
- CSMA / CD
- topology:
- Star
- LAN port:
- 24 x 10/100 / 1000Mbps Auto Negotiation, Auto-MDIX ports,
- Address Table:
- 8K entries per device
- Data transfer rate:
- Ethernet: 10 / 20Mbps (Half / Full-Duplex)
- Fast Ethernet: 100 / 200Mbps (Half / Full-Duplex)
- Gigabit Ethernet: 2000Mbps (Full-Duplex)
- Data RAM buffer:
- 400kbytes
- Bandwidth:
- 48Gbps
- LEDs LEDs:
- Per Unit: Power, System, Per Port (RJ-45): Link / Activity, 100Mbps.
- Power consumption:
- 32 Watts. Max
- Dimensions (WxHxD):
- 440 x 210 x 44 mm (17.32 x 8.2 x 1.73 inches)
- Weight:
- 2kg. (4.48 lbs)
- Temperature:
- Operation: 0 ° ~ 40 ° C (32 ° ~ 104 ° F)
- Storage: -10 ° ~ 70 ° C (14 ° ~ 158 ° F)
- Humidity:
- 10% ~ 90% (no-condensed)
- certificates:
- FCC Class A, CE Mark A, VCCI-A
الشركة المصنعة
TRENDnet
مواصفات المنتج العامة
منفذ شبكة 10/100/1000
- 24
Dimension
- 440 x 210 x 44 mm (17.32 x 8.2 x 1.73 inches)
الوزن
- 2kg. (4.48 lbs)
استهلاك الطاقة الأقصى
- 32 Watts. Max
نطاق درجة الحرارة
- Operation: 0 ° ~ 40 ° C (32 ° ~ 104 ° F) ,
- Storage: -10 ° ~ 70 ° C (14 ° ~ 158 ° F)
