TEG-ECTX-Gigabit PCI Express Adapter
الرجاء تسجيل الدخول حتى نتمكن من إخطارك بالرد
The Gigabit PCI Express Adapter is a high performance network adapter that supports advanced management and power savings
functionality for system administrators. Full-Duplex technology generates data rates of up to 2Gbps over a motherboard’s
high-speed PCI Express Bus architecture. Jumbo Frame support further optimizes throughput performance.
Supports SNMP v1, Pre-Boot Execution Environment (PXE) 2.1, Remote Program Load (RPL) and Wake-on-LAN (WOL). Optimize network
performance with VLAN tagging and Layer 2 Priority Tagging. Optimizes power consumption with advanced Configuration Power
Management Interface 2.0 (ACPI) technology.
- 1 x 10/100/1000Mbps Auto-MDIX WAN port
- PCI Express 1.0a compliant
- Incorporates Advanced Configuration Power Management Interface (ACPI) 2.0
- Wake-On-LAN (WOL)
- TCP segmentation / large send offload
- IEEE 802.1Q VLAN tagging and IEEE 802.1p Layer 2 priority tagging
- IEEE 802.3x full-duplex Flow Control
- Microsoft NDIS5 (IP, TCP, UDP) checksum off-load
- SNMP v1 supported
- Preboot eXecution Environment (PXE) 2.1 and Remote Program Load (RPL)
- Jumbo Frames up to 7K
- Intuitive cable diagnostic utility
-
- Hardware
- Standards
- IEEE 802.3 10Base-T Ethernet
- IEEE 802.3u 100Base-TX Fast Ethernet
- IEEE 802.3ab 1000Base-T Gigabit
- IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p
- Standards
- Ethernet: UTP Cat. 3, 4, 5, EIA/TIA-568 100-ohm STP
- Fast Ethernet: UTP Cat. 5, EIA/TIA-568 100-ohm STP
- Gigabit: UTP Cat. 5, 5E, 6 EIA/TIA-568 100-ohm STP
- Protocol
- SNMP v1
- Interface
- Port PCI Express / Gigabit Ethernet
- Power Consumption
- 2.3 watts (max)
- Diagnostic LED
- Link, activity
- Supported OS
- Windows 2000/2000 Server/XP(32/64-bit)/2003 Server/Vista (32/64-bit)/Win 7 (32/64-bit)
- Novel NetWare Server 5.x / 6.x
- Linux Kernel 2.4.x / 2.6.x
- Data Rate
- Ethernet: 10Mbps/20Mbps (half/full-duplex)
- Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)
- Gigabit: 2000Mbps (full-duplex)
- Dimension
- 109 x 83mm (4.3 x 3.3in)
- Weight
- 80g (2.88oz)
- Temperature
- Operating: 0°C ~ 45°C (32°F ~ 113°F)
- Storage: -10°C ~ 70°C (14°F ~ 158°F)
- Humidity
- 5%~95% (non-condensing)
- Certifications
- CE, FCC
Package Contents
- TEG-ECTX
- Multi-Language Quick Installation Guide
- CD-ROM(Drivers & User’s Guide)
الشركة المصنعة
TRENDnet
مواصفات المنتج العامة
Interface
- Port PCI Express / Gigabit EthernetPort PCI Express / Gigabit Ethernet
Dimension
- 109 x 83mm (4.3 x 3.3in)
الوزن
- 80g (2.88oz)
نطاق درجة الحرارة
- Operating: 0°C ~ 45°C (32°F ~ 113°F) ,
- Storage: -10°C ~ 70°C (14°F ~ 158°F)
