Powerline

• 1 x 10/100Mbps Auto-MDIX Ethernet port
• Connect one 200Mbps** Powerline AV Adapter to the Internet and then plug in up to 15* additional Powerline AV adapters for instant building connectivity
• One-touch Sync button networks adapters quickly
• Share data intensive files, play games, download music, and more at faster data transfer rates
• Advanced 128-bit AES encryption to ensure total network security
• Neighbor network support for up to 4 overlapping networks
• Tri-color LED Indicator
• Network signal transmits up to 300 meters (984ft.)
• Auto QoS support through traffic classification and multiple priority queuing
• Optional management utility compatible with Windows 7 (32/64-bit), Vista (32/64-bit), and XP (32/64-bit) operating systems

Wireless

• Integrated high performance wireless n access point
• Based on IEEE 802.11n technology and compliant with IEEE 802.11b/g standards
• High-speed data rates of up to 300Mbps*** with IEEE 802.11n
• One-touch Wi-Fi Protected Setup (WPS) button connects wireless clients quickly
• Supports Access Point or Access Point (AP) Client (wireless adapter) mode
• In Access Point mode: expand a wireless network using Repeater mode (listed as AP Mode Support), Wireless Distribution System (WDS), or Mesh mode (bridging)
• MAC filter feature for added security (AP mode only)
• Wireless security up to WPA/WPA2-RADIUS
• Create a weekly schedule to enable or disable wireless network
• Wi-Fi Multimedia (WMM) Quality of Service (QoS) support
• Broadcast up to 4 SSIDs with different wireless encryption
• Web graphical user interface provides backup, configuration, and firmware management
• Wireless indoor coverage up to 100 m (328 ft.)***
